M100SA – Mechanical Brakes

  • Capable of 10,000 Lbs. of clamp force
  • Self adjusting for friction pad wear
  • Fully sealed internal ball ramp mechanism
  • Fully assembled, with air chamber mounted for either CW or CCW operation
  • Quick change pads, retained by mount pins
  • Fast response – capable of 100 milliseconds
  • Chamber can be positioned in 120 degree increments
  • Mechanical release using a wrench

*Shipping Available Within the USA Only

Share this product

Specs

WEIGHT
36.5 Lbs.
ROTOR DIAMETER
10 To 40 In
ROTOR THICKNESS
.375" To .750"
LINING TYPE
Sintered, Non-Asbestos Organic
TOTAL LINING AREA
14.8 Sq. In.
USABLE LINING THICKNESS PER PAD
.47 In.
